China Self-Priming Jet Pump (JETTR) with CE Approved

Product Description

JETTR series self-priming pumps are high efficient jet pumps with excellent suction even when there are air bubbles. The pump consists of a single impeller, centrifugal pump and a ejector pump.
The series pumps are particularly suitable for water supplying in domestic installations, small-scale agriculture watering and where self-priming operation is demanded.

PUMP
Pump Body: Cast Iron
Impeller: Brass/Techno-polymer
Mechanical Seal: Carbon / Ceramic/ Stainless Steel

MOTOR
Single Phase
Heavy Duty Continuous Work
Motor Housing: Aluminum
Shaft: Carbon Steel / Stainless Steel
Insulation: Class B / Class F
Protection: IP44 / IP54
Cooling: External Ventilation
Self-Priming Jet Pump (JETTR) with CE Approved

Self-Priming Jet Pump (JETTR) with CE Approved

220V/50Hz, 230V/50Hz, 110V/60Hz & 115V/60Hz models are available on request.

Type	Power		Q.MAX L/min	H.MAX m	S.Head m	Inlet/Outlet	Packaging Dimension mm	G.W. Kg
Type	KW	HP	Q.MAX L/min	H.MAX m	S.Head m	Inlet/Outlet	Packaging Dimension mm	G.W. Kg
JET150TR	1.1	1.5	85	61	9	1.5"/1"	525×250×300	31
JET220TR	1.5	2	100	61	9	1.5"/1"	525×250×300	32
