Multistage Automatic Built-in Sensor Switch Garden Water Pump
Multistage High Pressure Water Pump Built-in floatThe pump is designed to pump water from big tanks to main pipes of drink water networksor irrigation networks. Floating switch controls the pump to start on/off to realize the automatic work at a site.Built-in automatic types is available.Application......
Send Inquiry
Product Description
The pump is designed to pump water from big tanks to main pipes of drink water networks
or irrigation networks. Floating switch controls the pump to start on/off to realize the automatic work at a site.
Built-in automatic types is available.
Applications
Key features
Equipped with 3 or 4 impellers to ensure powerful water supplied with high pressure.
Pumps could both available with float switch or integrate sensor switch. When appliied with sensor switch , pump automatically on/off by flow sensor .
Sturdy stainless pump housing , anti-rust stainless steel roter shaft, maintainance-free ball bearings, solid seal make MEDAS pumps particularly durable and problem-free.
Compact design of the pump with vertical outlet and comfortable ergonomic handling for easy transfer and operation.
Intergrated filter prevent the pump from suctioning too large impurities.
Low consumption electric motor with overload protection ensure safe operation.
Parameter
| Model | MQ 1000 INOX MULTI | MQ 1200 INOX MULTI | MQ 1000A INOX MULTI | MQ 1200A INOX MULTI | |
| Power | W | 1000 | 1200 | 1000 | 1200 |
| Flow | l/h | 6700 | 6500 | 6700 | 6500 |
| Head | m | 36 | 44 | 36 | 44 |
| Max submersible depth | m | 8 | 8 | 8 | 8 |
| Outlet | inch | G1 | G1 | G1 | G1 |
| Solid | mm | 0.5 | 0.5 | 0.5 | 0.5 |
| IP | Grade | IPX8 | IPX8 | IPX8 | IPX8 |
| Impeller | pcs | 3 | 4 | 3 | 4 |
| Weight | kg | 9.1 | 9.3 | 9.68 | 9.98 |
| Loading qty | pcs | 1680/2680/3360 | 1680/2680/3360 | 1680/2680/3360 | 1680/2680/3360 |
The MEDAS Group is a developing leading industrial in China in the two business
areas of pump and garden care and consumer goods. The MEDAS Group's products
and services are designed to improve the quality of life by providing solutions that
are both innovative and beneficial.
Since being founded in 1997, MEDAS has rapidly emerged as a company spanning
the entire domestic market. MEDAS has always oriented itself towards fostering
talent and technology-based production, guiding our success with customer support
and trust. Almost all our office staff have a bachelor degree or above and vast operational experience, helping to efficiently provide design and experimental operation as well.
The principle of "Quality comes first" is deeply embedded in the heart of every Medaser,
a principle which MEDAS also reflects on the large scale.
Our service
We take customer needs very seriously. Tasks and challenges are solved together
with the customers - using our high expertise in product technologies, process
technologies and logistics. Our professionalism guides us through the development
and production process.
Knowing the customer is the priority of all we do.With the customers' specific
technical data and requirements fully in mind.We make a promise that every
process of the cooperation is clear. As production begins, we focus on working along
multiple lines. Even once the order has closed, MEDAS still provides meticulous
after-sales service.
FAQ
Q: What is our policy of the payment term?
A: -100% advanced payment is the first option we prefer to taking.
-Any order valued less than USD10,000 has to be 100% prepaid.
-Irrevocable L/C at sight is acceptable for most of business.
-Irrevocable L/C with less than 60-day term will be only acceptable for some
business after negotiation.
-Any L/C with more than 60-day term will not be acceptable.
-D/P at sight will be acceptable for some business after negotiation, while other
terms will not be acceptable.
-D/A and O/A will not be acceptable basically.
-Partial payment is negotiable, but normally we require the advanced payment
no less than 30%, and the balance to be paid before shipment
Q: How long will be the lead time for the orders to us?
A: -Normally the lead time for our orders is 45-60 days, depending on the order
quantity and our production schedule.
-Normally the lead time is calculated from the date of receiving the L/C or advanced
payment as agreed in contract.
-Some rush orders might be fulfilled within 30 days or even shorter time, until we
finally approve.
Q: Do we have minimum order requirement?
A: -Yes, the minimum order value has to be USD2,000.
-Any order with less than USD2,000 will be only acceptable after negotiation.
-Sample order is exception.
-As for the minimum quantity for each product, please contact with us for further information.
