China CPT Series Jet Pump Marine 0.5 HP Water Pump

Product Description

China Huanggong Machinery Group Co.,Ltd.
Specialist in marine pump industry for over 35 years.

CPT Marine Injection pump with CCS approval

1. This injection water pump is used for drainage.
2. Pump suction flange axis perpendicular to the pump body axis.
3. With self-priming characteristic, it can work continuously and stably. Easy installation, no other moving parts, long service life.
4. Mainly used for ship/warship's draining system. Also can be used for environmental, chemical, water, building materials and other industries,such as pumping fresh/sea water, mixing liquids, river dredging, transporting powders and so on.

Model Explanation

For the Model CP5-0.3T

65 stand for pump capacity (m3/h)

CP stand for Angle boat marine-type water jet pump

0.5 stand for pump's working pressure (Mpa)

T stand for suction flange axis perpendicular to the axis of the pump body

Main Technical parameter:

Model	Flow m 3 /h	Water Pressure MPa	Water Consumption. m3/h	Suction Head m	Discharge Pressure MPa	Pump Weight kg
CP5-0.3T	5	0.3	6	4	0.05	19.5
CP10-0.3T	10	0.3	12	4	0.05	23.5
CP15-0.3T	15	0.3	19	4	0.05	28
CP20-0.3T	20	0.3	24	4	0.05	31
CP30-0.3T	30	0.3	36	4	0.05	50
CP40-0.3T	40	0.3	47	4	0.05	49.5
CP50-0.3T	50	0.3	55	3	0.06	75
CP100-0.3T	100	0.3	110	3	0.06	94.5
CP5-0.7T	5	0.7	3.6	4	0.08	14
CP10-0.7T	10	0.7	7	4	0.08	20
CP20-0.7T	20	0.7	14	4	0.08	28.5
CP30-0.7T	30	0.7	21	4	0.08	32
CP30/20-0.7	30	0.7	40	5	0.15	32
CP50-0.7T	50	0.7	35	4	0.08	48
CP60-0.7T	60	0.7	50	6	0.06	55.5
CP80-0.7T	80	0.7	90	5	0.10	75
CP100-0.7T	100	0.7	60	2	0.09	71.5
CP150-0.7T	150	0.7	100	2	0.09	77
CP200-0.7T	200	0.7	120	2	0.09	106
CP100-0.7G	100	0.7	90	5	0.09	77
CP15-0.5T	15	0.5	25	7	0.11	28
CP10-1.0T	10	1.0	16.7	5	0.2	16
CP50-1.0T	50	1.0	64	5	0.2	52
CP100-0.2T	100	0.2	305	3	0.07	120

After sale service
One year Warranty time. Within warranty period, for non-artificial quality problem, we will repair and replace spare parts for free. Except for normal wear and tear of parts.

We can provide all kind of pump
screw pump
centrifugal pump
vortex pump
gear pump
diaphragm pump
Marine hydraulic deep well cargo pump
Marine electric deep well cargo pump
hand pump
Marine bulkhead seal
Marine tank washing machine
