China Huanggong Machinery Group Co., Ltd.
Specialist in pump industry for over 40 years.

Product Description
Twin screw pumps is the best choice to be used as Fuel Oil pump, Diesel Oil pump, Heavy Oil Transfer Pump, lube oil Pump, lubricating oil pump or chemical pump.
Twin-screw pump can transfer various non-solid contained fluid medium or extremely high viscosity medium. They have wide availability and high reliability for lubricating or non lubricating medium, for corrosive medium or gas-liquid mixture.
Capacity: 0.5-1500m3/h
Pressure: 0.1-1.6MPa
Viscosity: 0.5-1000mm2/s
Temperature: -30 - 200 C
Medium: Various lubricating oil and fuel oil

Certificate: ISO9001: 2000, CE, CCS, BV, NK, KR, ABS, RINA, GL, etc.
Construction: Horizontal, vertical, portable structure, heating chamber
Safety: Explosion-protection, water-protection, safety valve, alarming sensor.

Performance parameter of bi-suction twin screw pump
Speed n=1450r/min
Model	ΔP Bar	Viscosity(mm 2 /s)
		1		15		35		75		150		350		750		1500
		Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw	Flow M 3 /h	Power Kw
2HM7000-100	2	466	32	468	35	469	37	470	37.6	471	46	472	55	473	63	473	70
	4	438	60	441	65	443	71	445	71.2	446	87	447	102	448	115	448	130
	6	424	83	425	95	428	103	430	103	431	125	432	145	433	165	433	185
	8	406	107	410	120	413	133	415	133	416	160	417	186	418	212	419	240
	10	388	128	393	145	397	160	400	160	401	195	402	225	404	256	406	285
	12	373	148	378	168	382	185	386	185	388	225	390	260	393	296	396	330
	14			352	186	362	206	368	206	370	250	373	290	377	330	380	370
	16			328	205	342	227	354	227	357	280	360	320	364	363	368	405
	18					324	244	338	244	341	300	344	342	347	390	350	440
	20					295	250	310	250	314	330	318	350	342	400	345	450
2HM7000-128	2	590	40	595	45	598	48	600	48	601	58	603	70	605	80	608	90
	4	565	75	570	85	572	92	574	92	575	112	577	130	580	150	582	165
	6	545	108	550	120	553	133	555	133	557	160	560	188	563	212	567	240
	8	525	138	530	155	533	172	536	172	538	208	540	240	543	275	547	310
	10	500	166	508	186	513	207	517	207	520	250	523	257	526	330	530	370
	12	480	192	486	216	493	240	498	240	500	290	503	336	506	384	510	430
	14			450	240	462	265	470	265	472	320	475	370	478	420	482	475
	16					420	290	430	290	432	350	435	406	438	460	442	520
