Melt Pump for Reaction Kettle

Product Description

Melt Pump for Reaction Kettle

This kind of GM-LK series melt pump installed under the reaction kettle as discharge pump

GM-LK series melt pump is mainly used for transporting medium or high viscosity medium out of the vacuum reaction kettle. On basis of large suction inlet flange design, the high viscosity medium is able to absorb inside under vacuum conditions. This series of melt pump is primarily applicable for ABS, PS, PMMA, PBT, PT, etc.

Technical Parameter
Material for Melt Pump Body:Stainless Steel
Material for Gear: M2 Steel (Optional)
Material for Sliding Bearing: High Temperature Tool Steel or Stainless Steel
Shaft Sealing: Packing Sealing
Heating System: Heating Medium or Conduction Oil (ZB-K series melt pump adopts electrical heating.)
Model/Flow Range: 0.5CC - 2500CC, 0.5cm3/rev - 2500cm3/rev

Technical data:
1. Rotate speed: ≤ 60rpm(Adjustable)
2. Temperature: 400° C (max. )
3. Max. Outlet pressure: 350Bar
4. Max. Differential pressure: 275Bar
5. Heating method: Stainless Steel Cartridge Heater
6. Fastening parts: 12.9 high-strength screws
7. Voltage: 380V(Others are optional)
8. Frequency: 50Hz(Others are optional)

Benefits of Applying Gmach GM-LK series Melt gear Pump:
1. Reducing stress on the extruder by means of shifting the job of building pressure to the melt pump;

2. Increasing the hourly output;

3. Removing the output variations and pressure pulsations, thus greatly improving the product quality;

4. Saving raw material by means of tighter manufacturing tolerances;

5. Improving the the dimensional accuracy during the production of sheets and profiles;

6. Optimizing the surface and optical quality during the production of films, sheets and profiles;

7. Improving the product quality with regard to homogeneity and pellet size in compounding;

8. Extending the lifetime of the upstream machinery;

Product show

Installation of this kind of pump

Technical data

Type	Volume (cc/r)	Max roate speed (r/min)	Outlet pressure (MPa)	Inlet pressure (MPa)	Rate of flow m3/h			Temperature
Type	Volume (cc/r)	Max roate speed (r/min)	Outlet pressure (MPa)	Inlet pressure (MPa)	Low viscosity material 1-1000Pa·s	High viscosity material 1000~8000Pa·s	Ultra-high viscosity material >=8000Pa·s	Temperature
GM-LK-100	100	100	≤35	Vacuum~5.0	≤0.51	≤0.36	≤0.21	≤350ºC
GM-LK-160	160	100			≤0.82	≤0.57	≤0.34
GM-LK-200	200	100			≤1.0	≤0.7	≤0.4
GM-LK-250	250	100			≤1.3	≤0.9	≤0.5
GM-LK-355	315	100			≤1.6	≤1.1	≤0.7
GM-LK-500	500	100			≤2.6	≤1.8	≤1.1
GM-LK-750	750	80			≤3.1	≤2.1	≤1.3
GM-LK-1250	1000	80			≤4.1	≤2.9	≤1.7
GM-LK-2000	2500	80			≤10	≤7	≤4
GM-LK-3150	3150	80			≤13	≤9	≤5
GM-LK-4500	4500	60			≤14	≤10	≤6
GM-LK-6300	6300	60			≤19	≤13	≤8
GM-LK-8000	8000	60			≤24	≤17	≤10
GM-LK-12000	12000	50			≤31	≤21	≤13
GM-LK-25000	25000	50			≤64	≤45	≤27
Remark:the melt gear pump flow is associated with the work speed, material viscosity, pressure, So the model selection please ask for us.

Quality inspection
We take only firstclass steel and check every production procedure to ensure every dimension is produced precisely. A final complete inspection will be executed  before delivery.

Commissioning
We provide the operation manual for customers to gudie to install the screen changer, and at the requirement of user, salers should send technician to install and commissioning the die at site of Buyers, expenses of the trip should be borne by Buyers.

After-sales service
12 months with proper operation by user, all the spare parts shall be replaced free of charge under guarantee period, fee for transportation and packing will be borne by users.
