Multistage Inline Water Pump with SGS Certificate

DFLMultistage pipeline pump

Applications

Lives water supply
Fire-fighting water supply
Whole set water supply equipment and other boosting system's pressure-stability pump
Water supply in boiler system
Boosting and circulating in technology processes
Transfer clean liquid


Operating conditions

Capacity range: 1.4-194.4m/h
Head: 20-230m
Speed: 2900r/min
System Max working pressure: 2.5Mpa
Liquid temperature: -15C to 105C
Environment temperature: No more than 40C
Motor's degree of protection: IP44 or IP54
Motor's class of insulation: B or F

Capacity: 1.4-194.4m³ /h with 2900rpm
Head: 20-230m
Medium Temperature: -15degree~105degree
Max working pressure: 2.5MPa
Material: Cast iron, SS
Motor: 380V, 415V, 660V, IP54, IP55, 50Hz, 60HZ
