Home > Products > Centrifugal Pump > Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles
                                    Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles
                                    • Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 PolesBare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles
                                    • Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 PolesBare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles
                                    • Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 PolesBare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles
                                    • Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 PolesBare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles

                                    Bare Pump with Shaft Particles Water Pump Ih125 -100-315/4 Poles

                                    - Name of pump:Bare pump with shaft particles water pump- Pump Type: Centrifugal Pump- Pump model:IH125-100-315/4 poles- Pump brand: ATACH-Installation Type: horizontal coupling - Impeller Quantity: 1 pcs- Rated pump capacity: 100 m3/h- Rated pump head: 32 m- Power/speed:15 Kw/1450 r.p.m- Power supp......

                                    Send Inquiry

                                    Product Description

                                    Bare Pump with Shaft Particles Water Pump Ih125-100-315/4 Poles


                                    - Name of pump:Bare pump with shaft particles water pump

                                    - Pump Type: Centrifugal Pump

                                    - Pump model:IH125-100-315/4 poles


                                    - Pump brand: ATACH

                                    -Installation Type: horizontal coupling

                                    - Impeller Quantity: 1 pcs

                                    - Rated pump capacity: 100 m3/h

                                    - Rated pump head: 32 m

                                    - Power/speed:15 Kw/1450 r.p.m

                                    - Power supply:3 phase/380V/50HZ
                                    (also supply special voltage,special frequency, explosion-proof motor, High efficiency and energy saving motor )

                                    - Material Supply: SUS304,SUS316,SUS316L,Duplex Stainless Steel 2205,etc

                                    - Shaft Seal: Mechanical seal(Water Cooling Device Available)

                                    - Inlet / outlet : 125mm*100mm



                                    If you need other specifications or parameters of IH series Industrial pumps, please contact us in detail.

                                    Bare Pump with Shaft Particles Water Pump Ih125-100-315/4 Poles
                                    Bare Pump with Shaft Particles Water Pump Ih125-100-315/4 Poles
