150wq250-22-30 China Electric Submersible Pump Factory Price Mechanical Seal

Product Description

Notice:
Free ports in various countries are as follows:

Karachi ,Bangkok ,Singapore ,Antwerp ,Budapest ,Jakarta, Chennai ,Durban

WQ series Vertical Inline Sewage Submersible Dirty Water Suction Pump

150wq250-22-30 China Electric Submersible Pump Factory Price Mechanical Seal

Characteristics:

150WQ250-22-30TYPE SEWAGE PUMP
Capacity:	_250m3/h
Head:	_22m
Power:	_30kw
Color:	As Customer Required
cast meterial:	_{cast iron}
Wet ends material:	Cast iron
Shaft material:	_45#steel
Shaft seal :	Mechanical seal

Features:

150wq250-22-30 China Electric Submersible Pump Factory Price Mechanical Seal

Conditions of use

1. Medium temperature should not be over 40degree, the density no larger than 1200kg/m, and the PH value within5-9.
2. During running, the pump must not be lower than the lowest liquid level.
3. The maximum diameter of the solid grain going through the pump has not be larger than 50% of the pump outlet

WQ Pump Performance

Item	Type	Outlet diameter (mm)	Capacity (m3/h)	Head (m)	Speed (r/min)	Power (kw)	Efficiency (%)
1	50WQ15-8-0.75	50	10-20	7-10	2825	0.75	52
2	50WQ15-16-1.5	50	10-20	10-18	2840	1.5	52
3	65WQ30-10-2.2	65	20-45	8-12	1420	2.2	62
4	65WQ30-35-7.5	65	20-45	30-37	1440	7.5	50
5	80WQ50-35-11	80	40-75	27-40	2900	11	55
6	80WQ50-40-15	80	40-75	37-42	2900	15	52
7	100WQ80-36-18.5	100	65-120	30-40	2900	18.5	55
8	100WQ80-40-22	100	65-120	35-45	2900	22	55
9	150WQ150-40-30	150	100-200	33-42	1470	30	65
10	200WQ400-27-45	200	250-500	24-35	1480	45	74
11	250WQ500-25-55	250	400-700	16-22	980	55	74
12	300WQ1000-20-75	300	800-1400	15-23	990	75	82
13	350WQ1100-25-110	350	900-1500	18-30	980	110	76
14	350WQ1500-40-250	350	1200-2000	33-42	740	250	80
15	400WQ2000-36-280	400	1500-2800	27-43	745	280	80
16	500WQ3000-11-132	500	2000-4000	8-14	745	132	75
17	600WQ4000-12-200	600	3000-6000	7-16	745	200	72

*The above pump performance for reference only, details please contact us!

150wq250-22-30 China Electric Submersible Pump Factory Price Mechanical Seal

FAQ

1. What is your product range?
A: centrifugal pump. Centrifugal pump includes slurry pump, gravel pump, clean water pump, sewage pump, chemical pump, self-priming pump and diesel engine pump.

2. What's your MOQ, payment term and lead time?
A: MOQ for centrifugal pump is 1set, MOQ for conveyor belt is 100cbm.
Payment Term: T/T, L/C, Western Union, Paypal and Trade Assurance.
Lead time: in general 7 working days for slurry pump, 15working days for water pump.

3. What information should I let you know if I want to get a quotation:
A: Pump capacity, pump head, medium, medium temperature, pump material, quantity, if possible, please also provide the pump model you are using now, price will be calculated as per the pump model, if not, we will recommend relevant product for reference.

4. If I put a bigger motor on my pump, will it pump more?
A: No. The amount of water and the pressure (head) that a centrifugal pump process is related to the rotational speed, impeller diameter and size of the impeller vanes.

5. Do you impact the finished product?
A: Yes, each batch of production and finished product will be quality checked strickly before delivering, testing report or video can be sent to clients for reference.

6. How do you ship the finished product?
A: By sea, By air, By international express.

Inquiry of Pump

1. Head: _____meter
2. Capacity: _____m3/h
3. Liquid media: ______
4. PH: _____
5. Concentration: ____%
6. Temperature: _____degree
7. Specific density; ______kg/m3
